Holiday Beach Toe Characteristics 1999
Identification_Information
Data_Quality_Information
Spatial_Data_Organization_Information
Spatial_Reference_Information
Entity_and_Attribute_Information
Distribution_Information
Metadata_Reference_Information
Identification Information
Section Index
Citation:
Citation Information:
Originator:
Oregon Department of Land Conservation and Development,
Shoreland Solutions
Publication Date: 19990630
Title: Holiday Beach Toe Characteristics 1999
Edition: NA
Geospatial Data Presentation Form: Map
Publication Information:
Publication Place: Salem, Oregon
Publisher: Oregon Department of Land Conservation and Development
Online Linkage: http://www.lcd.state.or.us/coast/
Larger Work Citation:
Citation Information:
Originator:
Shoreland Solutions; Oregon Department of Land Conservation
and Development
Publication Date: June, 1999
Title:
Oregon Coastal Natural hazards Geographic Information
System (Version 99.1)
Publication Information:
Publication Place: Salem, Oregon
Publisher:
Shoreland Solutions; Oregon Department of Land Conservation
and Development
Online Linkage: http://www.lcd.state.or.us/coast/
Description:
Abstract:
Field work to obtain data needed to develop this layer was
carried out by Shoreland Solutions during late August-early
September of 1996 and late August-early September of 1998.
Specifically, the location and elevation of reference
features including the vegetation line, toe of the
foredune, crest of the foredune, toe of the bluff, and
crest of the bluff were established at ~150 to 300 foot
increments along the study area shoreline. V8-video images
of the shoreline morphology was also collected at each of
these locations. All elevations are referenced to the
National Geodetic Vertical Datum (NGVD) of 1929. Categories
within the attribute field Toe Character are defined as
follows: talus (talus); no talus (not); open sand (os);
hydrophillic vegetation (hveg); beach grass (grass);
vegetated dune (vdune); driftwood (dw); cobble beach
(cobble); shore protection structure (sps); seawall (SW);
and riprap revetment (RR). Categories within the attribute
field Vegetation Cover are defined as follows: less than
25% (25-); between 25 and 50 % (25+); between 50 and 75%
(50+); and greater than 75% (75+).
Purpose:
The' Coastal Natural Hazards Geographic Information System'
(CNHGIS) is a database, decision support and tracking
system intended to assist city and county planners, state
agency representatives, and others involved in the
management of chronic coastal natural hazards
Time Period of Content:
Time Period Information:
Range of Dates/Times:
Beginning Date: 1996
Beginning Time: Unknown
Ending Date: 1999
Ending Time: Unknown
Currentness Reference: 1999
Status:
Progress: Complete
Maintenance and Update Frequency: Continually
Spatial Domain:
Bounding Coordinates:
West Bounding Coordinate: -124.0736
East Bounding Coordinate: -124.0659
North Bounding Coordinate: 44.5897
South Bounding Coordinate: 44.5591
Keywords:
Theme:
Theme Keyword Thesaurus: None
Theme Keyword: Beach
Theme Keyword: Erosion
Theme Keyword: Shoreline
Theme Keyword: Shoretype
Place:
Place Keyword Thesaurus: None
Place Keyword: Lincoln
Place Keyword: Newport
Place Keyword: Oregon
Place Keyword: Pacific
Place Keyword: Holiday Beach
Access Constraints: None
Use Constraints: Not to be used for legal purposes. See Distribution Liability
Point of Contact:
Contact Information:
Contact Organization Primary:
Contact Organization: Shoreland Solutions
Contact Person: John Marra
Contact Position: Geologist
Contact Address:
Address Type: mailing and physical address
Address: 800 NE Oregon St #18
City: Portland
State or Province: Oregon
Postal Code: 97232
Country: USA
Contact Voice Telephone: (503) 373-0050
Contact Facsimile Telephone: (503) 731-4068
Contact Electronic Mail Address: marrajj@fbo.com
Native Data Set Environment: ArcView version 3.1 shapefile format
Data Quality Information
Section Index
Attribute Accuracy:
Attribute Accuracy Report: The Attributes are considered accurate.
Logical Consistency Report: The data are believed to be Logically Consistent
Completeness Report: The Data are complete
Positional Accuracy:
Horizontal Positional Accuracy:
Horizontal Positional Accuracy Report:
Confidence in the horizontal positional accuracy is
relatively high.
Vertical Positional Accuracy:
Vertical Positional Accuracy Report: NA
Lineage:
Source Information:
Source Citation:
Citation Information:
Originator:
Oregon Department of Land Conservation and Development,
Shoreland Solutions
Publication Date: 19990630
Title: Holiday Beach Toe Characteristics 1999
Edition: NA
Geospatial Data Presentation Form: Map
Publication Information:
Publication Place: Salem, Oregon
Publisher: Oregon Department of Land Conservation and Development
Online Linkage: http://www.lcd.state.or.us/coast/
Larger Work Citation:
Citation Information:
Originator:
Shoreland Solutions; Oregon Department of Land Conservation
and Development
Publication Date: June, 1999
Title:
Oregon Coastal Natural hazards Geographic Information
System (Version 99.1)
Publication Information:
Publication Place: Salem, Oregon
Publisher:
Shoreland Solutions; Oregon Department of Land Conservation
and Development
Online Linkage: http://www.lcd.state.or.us/coast/
Source Time Period of Content:
Time Period Information:
Range of Dates/Times:
Beginning Date: 1996
Beginning Time: Unknown
Ending Date: 1993
Ending Time: Unknown
Source Currentness Reference: 1999
Source Contribution:
Field work to obtain data needed to develop this layer was
carried out by Shoreland Solutions during late August-early
September of 1996 and late August-early September of 1998.
Specifically, the location and elevation of reference
features including the vegetation line, toe of the
foredune, crest of the foredune, toe of the bluff, and
crest of the bluff were established at ~150 to 300 foot
increments along the study area shoreline. V8-video images
of the shoreline morphology was also collected at each of
these locations. All elevations are referenced to the
National Geodetic Vertical Datum (NGVD) of 1929. Categories
within the attribute field Toe Character are defined as
follows: talus (talus); no talus (not); open sand (os);
hydrophillic vegetation (hveg); beach grass (grass);
vegetated dune (vdune); driftwood (dw); cobble beach
(cobble); shore protection structure (sps); seawall (SW);
and riprap revetment (RR). Categories within the attribute
field Vegetation Cover are defined as follows: less than
25% (25-); between 25 and 50 % (25+); between 50 and 75%
(50+); and greater than 75% (75+).
Process Step:
Process Description:
Field work to obtain data needed to develop this layer was
carried out by Shoreland Solutions during late August-early
September of 1996 and late August-early September of 1998.
Specifically, the location and elevation of reference
features including the vegetation line, toe of the
foredune, crest of the foredune, toe of the bluff, and
crest of the bluff were established at ~150 to 300 foot
increments along the study area shoreline. V8-video images
of the shoreline morphology was also collected at each of
these locations. All elevations are referenced to the
National Geodetic Vertical Datum (NGVD) of 1929. Categories
within the attribute field Toe Character are defined as
follows: talus (talus); no talus (not); open sand (os);
hydrophillic vegetation (hveg); beach grass (grass);
vegetated dune (vdune); driftwood (dw); cobble beach
(cobble); shore protection structure (sps); seawall (SW);
and riprap revetment (RR). Categories within the attribute
field Vegetation Cover are defined as follows: less than
25% (25-); between 25 and 50 % (25+); between 50 and 75%
(50+); and greater than 75% (75+).
Process Date: 1999
Cloud Cover: 0
Spatial Data Organization Information
Section Index
Direct Spatial Reference Method: Point
Point and Vector Object Information:
SDTS Terms Description:
SDTS Point and Vector Object Type: Point
Point and Vector Object Count: 46
Spatial Reference Information
Section Index
Horizontal Coordinate System Definition:
Planar:
Map Projection:
Map Projection Name: Lambert Conformal Conic
Lambert Conformal Conic:
Standard Parallel: 43
Standard Parallel: 45.5
Longitude of Central Meridian: -120.5
Latitude of Projection Origin: 41.75
False Easting: 400000
False Northing: 0
Planar Coordinate Information:
Planar Coordinate Encoding Method: Coordinate Pair
Coordinate Representation:
Abscissa Resolution: 0
Ordinate Resolution: 0
Planar Distance Units: international feet
Geodetic Model:
Horizontal Datum Name: North American Datum of 1983
Ellipsoid Name: Geodetic Reference System 80
Semi-major Axis: 6378137
Denominator of Flattening Ratio: 298.257
Entity and Attribute Information
Section Index
Detailed Description:
Entity Type:
Entity Type Label: 7_toe.dbf
Entity Type Definition: Shapefile Attribute Table
Entity Type Definition Source: None
Attribute:
Attribute Label: Elev
Attribute Definition: elevation of dune/bluff toe in feet referenced to NGVD29
Attribute Domain Values:
Range Domain:
Range Domain Minimum: 8
Range Domain Maximum: 15
Attribute:
Attribute Label: face(%)
Attribute Definition: extent of vegetation cover on the dune foreslope or bluff
Attribute:
Attribute Label: H2ot
Attribute Definition: existence of seeps or springs
Attribute Domain Values:
Enumerated Domain:
Enumerated Domain Value Definition: None
Enumerated Domain Value: y
Enumerated Domain Value Definition: seeps of springs present
Attribute:
Attribute Label: Morphology
Attribute Definition: general morphologic setting of reference location
Attribute Domain Values:
Unrepresentable Domain: Character Field
Attribute:
Attribute Label: Ref
Attribute Definition: DOGAMI 1993 transect reference number
Attribute Domain Values:
Unrepresentable Domain: Character Field
Attribute:
Attribute Label: Ss_
Attribute Definition: Shoreland Solutions Reference Number
Attribute Domain Values:
Unrepresentable Domain: Character Field
Attribute:
Attribute Label: Toe_char
Attribute Definition: morphologic features associated with reference location
Attribute:
Attribute Label: Toe98_id
Attribute Definition: feature ID Number
Attribute Domain Values:
Range Domain:
Range Domain Minimum: 1
Range Domain Maximum: 48
Distribution Information
Section Index
Distributor:
Contact Information:
Contact Organization Primary:
Contact Organization: Oregon Department of Land Conservation and Development
Contact Person: Randy Dana
Contact Position: GIS Coordinator
Contact Address:
Address Type: mailing and physical address
Address: 800 NE Oregon St #18
City: Portland
State or Province: Oregon
Postal Code: 97232
Country: USA
Contact Voice Telephone: 503-731-4065 x 31
Contact Facsimile Telephone: 503-731-4068
Contact Electronic Mail Address: randy.dana@state.or.us
Resource Description: Holiday Beach Toe Characteristics 1999
Distribution Liability:
THE DATA AND ASSOCIATED DATA FILES ON THIS CD-ROM ARE
PROVIDED ""AS
IS,"" WITHOUT WARRANTY TO THEIR PERFORMANCE, MERCHANTABLE
STATE,
OR FITNESS FOR ANY PARTICULAR PURPOSE. THE ENTIRE RISK
ASSOCIATED
WITH THE RESULTS AND PERFORMANCES OF THE DATA IS ASSUMED
BY THE USER. THIS DATA IS NOT FOR NAVIGATIONAL OR LEGAL PURPOSES.
Custom Order Process: contact randy.dana@state.or.us
Available Time Period:
Time Period Information:
Single Date/Time:
Calendar Date: 1/1926
Time of Day: Unknown
Metadata Reference Information
Section Index
Metadata Date: 10/10/1999
Metadata Review Date:
Metadata Future Review Date:
Metadata Contact:
Contact Information:
Contact Organization Primary:
Contact Organization: Oregon Department of land Conservation and Development
Contact Person: Tanya Haddad
Contact Position: NOAA CSC Fellow
Contact Address:
Address Type: Mailing and physical address
Address: 800 NE Oregon St #18
City: Portland
State or Province: Oregon
Postal Code: 97232
Country: USA
Contact Voice Telephone: (503) 731-4065 x30
Contact Facsimile Telephone: (503)731-4068
Contact Electronic Mail Address: tanya.haddad@state.or.us
Metadata Standard Name: FGDC CSDGM
Metadata Standard Version: FGDC-STD-001-1998
SMMS Metadata report generated 10/2/2002
